| Dimensions |
Ø415 x 303 mm (Ø16.34 x 11.93″) |
| Weight |
Without Mount: 1.3 kg (2.87 lb) ! Please confirm weight !
With Mount: 1.8 kg (3.97 lb) |
| Enclosure Characteristics |
Aluminum / UV Stabilized Polycarbonate |
| Processor |
Quad-Core ARM Cortex A7 |
| Memory |
256 MB DDR3 |
| Networking Interface |
10/100/1000 Mbps Ethernet RJ45 |
| RF Connections |
Internal |
| Max. Power Consumption |
11W |
| Power Method |
Passive PoE (Pairs 4, 5+; 7, 😎 |
| Power Supply |
24VDC, 0.5A Gigabit PoE Adapter |
| Supported Voltage Range |
22 to 26VDC |
| ESD/EMP Protection |
Air/Contact: ± 24kV |
| Operating Temperature |
-40 to 60° C (-40 to 140° F) |
| Operating Humidity |
5 – 95% Noncondensing |
| Certifications |
FCC, IC, CE |
| Power |
Flashing White: Bootup in Progress
White: System Ready, Ubiquiti® Internet Service Provider (UISP™) Not Configured, Not Connected
Flashing Blue: System Ready, UISP Configured, but Cannot Connect
Blue: System Ready, UISP Configured and Connected |
| Ethernet |
Flashing Blue: Ethernet Traffic Detected |
| 5G |
Blue: Active Connection |
| 60G |
Blue: Active Connection |
| OS |
airOS® |
| Operating Modes |
PtP |
| Ubiquiti Specific Features |
Integrated 60 GHz and 5 GHz Radios, Discovery Protocol |
| Security |
WPA2 AES Only |
| Dashboard |
Yes |
| Wireless Settings |
Yes |
| Network Settings |
Yes |
| System |
Yes |
| Services |
UISP, Ping Watchdog, Web Server, SSH Server, NTP Client, System Log, Device Discovery |
| Tools |
Antenna Alignment Tool, Discovery Utility, Traceroute, Speed Test |
| Minimum Software Requirements |
Any Modern Web Browser |
| Operating Frequency* |
| US/CA |
U-NII-1 |
5150 – 5250 MHz |
| U-NII-2A |
5250 – 5350 MHz |
| U-NII-2C |
5470 – 5725 MHz |
| U-NII-3 |
5725 – 5850 MHz |
| 57,000 – 66,000 MHz |
| Worldwide |
5150 – 5875 MHz
57,000 – 66,000 MHz |
* Depends on regulatory region. |
| Max. Conducted TX Power |
25 dBm (5 GHz) |
| Channel Bandwidth |
| 60 GHz |
2160 MHz |
| 5 GHz |
20/40/80 MHz |
|
| Management Radio |
| US/CA |
2412 – 2462 MHz |
| Worldwide |
2412 – 2472 MHz |
|
| Antenna Gain |
| 60 GHz |
38 dBi |
| 5 GHz |
11 dBi |
|
| 5 GHz TX Specifications |
| Data Rate |
Avg Power
(dBm) |
Tolerance
(dB) |
| 1x BPSK (1⁄2) |
25 |
±2 |
| 2x QPSK (1⁄2) |
25 |
±2 |
| 2x QPSK (3⁄4) |
25 |
±2 |
| 4x 16QAM (1⁄2) |
25 |
±2 |
| 4x 16QAM (3⁄4) |
25 |
±2 |
| 6x 64QAM (2⁄3) |
24 |
±2 |
| 6x 64QAM (3⁄4) |
22 |
±2 |
| 6x 64QAM (5⁄6) |
22 |
±2 |
| 8x 256QAM (3⁄4) |
21 |
±2 |
| 8x 256QAM (5⁄6) |
21 |
±2 |
|
| 5 GHz RX Specifications |
| Data Rate |
Avg Power
(dBm) |
Tolerance
(dB) |
| 1x BPSK (1⁄2) |
-95 |
±2 |
| 2x QPSK (1⁄2) |
-95 |
±2 |
| 2x QPSK (3⁄4) |
-93 |
±2 |
| 4x 16QAM (1⁄2) |
-90 |
±2 |
| 4x 16QAM (3⁄4) |
-86 |
±2 |
| 6x 64QAM (2⁄3) |
-83 |
±2 |
| 6x 64QAM (3⁄4) |
-77 |
±2 |
| 6x 64QAM (5⁄6) |
-74 |
±2 |
| 8x 256QAM (3⁄4) |
-69 |
±2 |
| 8x 256QAM (5⁄6) |
-66 |
±2 |
|
