MIKROTIK CRS504-4XQ-IN, CLOUD ROUTER SWITCH

product description
Optical Cloud Router Switch CRS504-4XQ-IN is a suitable 19 “rackmount solution for access to 100 Gbps networks and as a small central optical switch, which offers 4x QSFP28 with 100 Gbps, 1x Ethernet port with passive PoE power supply and console RJ45 port. The switch can be powered via two redundant Hot-swap psus, DC connector/DC terminal block (36 – 57V DC), and via an Ethernet port supporting passive PoE with a voltage of 43 – 57V DC.The maximum power consumption of the device is 41W.

Gear
(4) 100G (QSFP28)
(1) 10/100/1000Mbps ethernet – with PoE IN support (43 – 57V DC)
(1) console RJ45 port
QCA9531 processor, 650 MHz frequency, Mipsbe
64 MB RAM
16 MB storage
RouterOS v7 Level 5 operating system
Wide range of power supplies – 2x redundant power supply, PoE, DC connector, DC terminal block
Package contents
(1) Equipment
(2) Power cord
(1) Holders for 19 “rack

Technical parameters
Connectors and interfaces
LAN speed: (1) 10/100Mbps
Optical interface: (4) 100G
Serial port: RJ45
Power supply
Power supply via PoE: 802.3af, 802.3at, 43 .. 57V DC
Redundant power supply: Yes
Power supply type: PoE, DC connector, DC terminal block, Mains (230V)
PoE types: PoE-In (only)
Max. power consumption [W]: 25
Power supply via connector/terminal block: 36 .. 57V DC, 230V AC
Physical characteristics
Design: Desktop, Rackmount
Number of “U” positions: 1
Fans: (2) 40 x 40 mm
Chassis: Metal
Buttons: Reset
Operating temperature [° C]: – 40 to 70
Width [mm] 320
Height [mm]: 44
Depth [mm] 185
Hardware
CPU: QCA9531
CPU frequency [MHz]: 650
Number of CPU cores: 1
Internal storage [MB]: 16
RAM [MB]: 64
Software
Web management: Yes
Management: Web interface
Functions: VLAN, QoS, L3
Operating system: RouterOS – L5
IPv6 support: Yes
