MIKROTIK L009UIGS-2HAXD-IN

MikroTik L009UiGS-2HaxD-IN

The L009 is more than just a router. This product line is up to 4 times faster than RB2011, has a modern ARM CPU with container support, an innovative housing that allows mounting up to four routers in one 1U space, more RAM, PoE and 2.5G SFP support.

This version comes with dual band 2.4GHz wireless connectivity.

Technical specifications

Hardware
Processor

• IPQ-5018 (ARM)

Number of CPU cores

• 2

Nominal CPU frequency

• 800 MHz

Operating system

• RouterOS v7

RAM size

• 512MB

Storage size

• 128 MB – NAND

MTBF

• Approximately 200,000 hours at 25°C

Ambient temperature tested

• -40°C to 70°C

Wireless options for the 2.4 GHz band
Wireless maximum transfer rate

• 574 Mbit/s/2 chains

Wireless standards

• 802.11b/g/n/ax

Antenna gain dBi

• 4

The wireless generation

• WiFi 6

WiFi speed

• AX600

Connection
Ethernet

• 8x 10/100/1000 Ethernet ports – 1x 1000 Ethernet port with PoE-out option

Optics

• 1x SPF port (2.5G supported)

Periphery
Serial console port

• RJ45

Number of USB ports

• 1x USB 3.0 type A

USB power reset

• Yes

Maximum USB current (A)

• 1.5

Power supply
Number of DC inputs

• 2 (DC jack, PoE-IN)

DC jack input voltage

• 24-56 V

Maximum power consumption

• 47 W

Maximum consumption without attachments

• 14 W

Type of cooling

• Passive

PoE in | input voltage

• 802.3af/at | 24-56 V

PoE-out
PoE-out ports Ether8 (passive)
Maximum output per port (18-30 V input) | (input 30-57 V)

• 1 A | 450mA
